The H4 Track-mounted cone crusher comes equipped with an optional pre screen with dirt conveyor and 3-deck screen. Applications for the H4 include: Abrasive and hard stone, Granite and basalt, secondary and tertiary crushing, River and sea gravel, quarrying and mining, production of aggregates for asphalt and concrete.
|Weight||35 t (38 sT)|
|Weight (with after screen)||46 t (50 sT)|
|Feeding size||up to 185 mm (7”)|
|Capacity||up to 250 tonnes / hour|
|Optional pre screen with dirt conveyor||1.200 mm (4’) x 1.800 mm (6’)|
|Optional 3-deck screen||3.600 mm (12’) x 1.500 mm (5’)|
|effective screen area||5,4 m² on each deck, with return conveyor|
