Watch the video: Sierra introduces HD3C-2020 three-compression baler
New heavy-duty ferrous scrap baler produces up to 50 bales per hour
Sierra International Machinery has introduced the HD3C-2020 three-compression baler, a stationary, 170-ton machine made with the highest degree of engineering. Equipped with four 125-horsepower electric motors, the HD3C-2020 produces high-density ferrous scrap bales.
According to Sierra, high production and versatility make the HD3C-2020 a profitable performer in virtually any scrap yard. These new units are equipped with a loading hopper and a compaction chamber with three movable walls, which by progressing in succession, realize the volume reduction. The compaction chamber surfaces are lined with replaceable, bolt-in tongue and grooved Hardox 450 wear-resistant machined steel liners.
For users of the HD3C-2020 baler, once compaction chamber is filled, a first hydraulic piston carries out the first volume reduction, and then refines material in a second compaction chamber. These machines are equipped with knives capable of cutting any metal scrap interposed between the hopper and the first chamber. At this point, a vertically disposed presser induces the second reduction in volume by leading material into a third compacting chamber.
The final density of the pack is obtained with a third transversal pressing by a third presser. The package thus obtained is ejected through an exit door, being able to be pushed by the same presser that made the third pressing.
Hopper Dimensions: mm 118" x 94.5"
Open Compaction Box Dimensions: mm 151" x 57" x 71"
Complete in-tank oil filtering
Side ejection door
Sidewall liners and compaction box floor made in Hardox 450 wear-resistant machined steel
Indicative Production Data
Bale Size: 19.7" x 19.7" x Variable
Average Bale Weight: 1200-1550 lbs.
Average Bale Density: 2.4 - 3t/m3
Average Hourly Bale Production: 45/50 bales per hour
Average Hourly Ton Production: 28/38 tons per hour
