Terex Minerals Processing Systems

TI4143

Horizontal shaft impactor


TI4143

With its hydraulic assist apron adjustment for quick setting changes, the TI4143 horizontal shaft impactor is a highly cost effective crusher that is easy to operate and easy to maintain.

There are four inspection doors plus a hinged side door for inspection access to the rotor, blowbars and aprons. The chamber hydraulically opens for general maintenance and for turning or replacing the blowbars. The quick-release wedge-lock system makes changing blowbars a breeze.

An optional blowbar jib crane is available for added flexibility and convenience.

VIEW FULL PROFILE

Specs

Key Specifications
Weight 21,915 lbs / 9940 kg
Capacity 90-300 tph / 80-270 mtph
Max Feed Size 20" / 500 mm
Rotor Dimensions 41"x43" / 1035x1100 mm
Motor size 180 hp / 130 kW
