LH 60 M
As a part of the new LH range, the LH 60 M Litronic sets the standard for efficient industrial freight and cargo handling in the 60-tonne operating weight class. The trendsetting design combined with innovative technology such as the patented ERC system makes this clearly apparent. Fuel saving of up to 25%, faster work cycles and higher loads emphasize the progress made. With key components manufactured in-house and driven by a powerful Liebherr 6-cylinder engine of the latest generation with Tier IIIB technology, the machine also performs the most demanding work with complete reliability. The newly configured driver’s working space in the LH series has resonating operating consoles and improved clarity, which enable working in comfort and safety. The standard central lubrication system and extremely easy and safely accessible maintenance points increase the efficiency, further.
|Operating weight||129,650 - 133,500 lb|
|Engine output||180 kW/241 HP (SAE J1349)|
|System performance||288 kW|
|Multi-tine grapple capacity||1.05 - 1.44 yd³|
|Shells for loose material capacity||1.70 - 5.23 yd³|
|Wood grapple capacity||2,325 - 3,255 in²|
